M AXI -C ON -X ? F IELD I NSTALLABLE C ONNECTORS
Specifications
Typical Specifications
Manufacturers Identifications
Description
Rating
Conductor Size
Configuration
Certification
Maxi-Con-X ?
Field Installable Connector & Custom Cable Assemblies
1.35 thru 23.0A, 600V
#12 Contacts, 12 thru 14 AWG
#16 Contacts, 16 thru 18 AWG
#20 Contacts, 20 thru 24 AWG
7 - #12 Contacts
10 - #16 Contacts
18 - #20 Contacts
20 - #20 Contacts
UL Recognized File #E150822 - 250V
CSA Certified File #181200 - 600V
Material Specifications
Cable Pin/Socket
Mechanical Backshell (Threaded)
Strap
Screws
Grommet
Coupling Ring
Contacts
Connector Body
O-Ring
Optional
Winged Coupling Ring
Cable to Cable
Mechanical Backshell (Threaded)
Grommet
Strap
Screws
Contacts
Connector Body
Panel Mount
Contacts
Panel Body
Gasket
Hex Nut
Optional
Dust Cap
Nylon, UL Recognized, Black
Nylon, UL Recognized, Black
Stainless Steel
Santoprene Rubber, Black
Nylon, UL Recognized, Black
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Neoprene Rubber, Black
Nylon, UL Recognized, Black (W/14482)
Nylon, UL Recognized, Black
Santoprene Rubber, Black
Nylon, UL Recognized, Black
Stainless Steel
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Neoprene Rubber, Black
Nylon, UL Recognized, Black
Santoprene Rubber, Black (Part No. 14295)
Gasket, O-Ring, & Grommet materials are
suitable for -40oC to +90oC (-40oF to +194oF).
Consult factory for higher temperature requirements.
Mechanical Specifications
Durability
Vibration
Hex Nut Torque
Electrical Specifications
Voltage
Current
Environmental Specifications
Temperature Rating
Corrosion
Weathertight
Molded Cable Assemblies
Watertight
Minimum 300 mate/unmate cycles without mechanical or electrical
failure
Coupling rings have overriding locking feature to prevent loosening or
separation of connector
All series hex nut to withstand 10-12 inch/lb tightening torque
600 V
See Electrical Current Rating Chart (Page 27)
-40oC to +115oC (-40oF to +239oF)
300 Hr salt spray contacts
Consult factory with specific application
(See Pages 3 & 26)
NEMA 6P, 13: IEC IP67
?
601 East Wildwood, Villa Park, Illinois 60181 ? Telephone (630) 834-7504 ? Fax (630) 834-8540 ? www.conxall.com
